AtlasIED DPA404 Networkable 4-Channel Power Amplifier with Optional Dante® – 400W
The AtlasIED DPA404 is a high-efficiency, multi-channel power amplifier designed for network-based audio installations in commercial environments. With four independent output channels delivering 100 watts each, it supports 4Ω, 8Ω, 70V, and 100V speaker loads and offers optional Dante® digital audio networking support. This rack-mountable solution is ideal for applications requiring flexibility, reliability, and scalable audio power in a single chassis.
$1,991.99
1 in stock
Guaranteed Safe Checkout
Features & Compatibility
The AtlasIED DPA404 is a high-efficiency, multi-channel power amplifier designed for network-based audio installations in commercial environments. With four independent output channels delivering 100 watts each, it supports 4Ω, 8Ω, 70V, and 100V speaker loads and offers optional Dante® digital audio networking support. This rack-mountable solution is ideal for applications requiring flexibility, reliability, and scalable audio power in a single chassis.
Box was opened to verify contents. Device never used or removed from box.
- 400W total power (4 x 100W @ 4Ω/8Ω or 2 x 200W @ 70V/100V)
- Optional Dante® audio networking module
- Onboard DSP with web GUI control
- Individual and global channel mute controls
- Remote and local control of level and standby modes
- 1U rack-mount chassis
- Signal Sense and Switchable High-Pass Filter
- Fault, Protect, and Clip LED indicators
- AtlasIED firmware updates and monitoring tools
Specifications:
- Form Factor: 1U Rack Mount
- Frequency Response: 20Hz – 20kHz ±1dB
- Total Harmonic Distortion: <0.1%
- SNR: >100dB
- Dimensions: 1.75″ H × 19″ W × 16.1″ D
- Weight: 16.2 lbs
- Warranty: Out of Warranty
Additional information
| Weight | 17 lbs |
|---|---|
| Dimensions | 17 × 20 × 2 in |
